Technical Specifications - The Moat Theatre 2024

Contact Information

The Moat Theatre
Abbey Street, Naas, Co. Kildare
Theatre Manager: Mr. Paul Seeber
Phone: (045) 883030
Email: manager@moattheatre.com

Theatre Technician
Phone: (045) 883030
Email: technical@moattheatre.com

Auditorium

  • Capacity: 200 Seat Proscenium Arch Theatre with Flat Stage and Tiered Seating

  • Note: If a Band/Orchestra is placed on the floor in front of the stage, 18 seats must be removed. Filming will result in a minimum loss of two seats; camera positions are very restricted.

  • Tech Support: Available for every show at no extra cost. Additional costs apply for Lighting and Sound Engineering.

Critical Stage Dimensions

  • Stage Depth (Proscenium to Cyclorama): 5,500mm

  • Proscenium Width: 10,000mm

  • Proscenium Height: 5,000mm

  • Height to Steel Grid (Max Flying): 9,000mm

Access

  • Get-in Doors (Stage Left): 1,700mm Wide x 2,000mm High

  • Scene Dock (Stage Left): 4,700mm Wide x 6,000mm Long x 4,100mm High

Floor Finish: Flat, Matt Black (Screwing/Nailing/Painting not permitted)



Lighting Spec

Stage Lighting

  • Dimmers: 48 No. 3kW Dimmers

  • Control Desk: ETC Ion XE with Touch Screen Monitor (1,000 Submasters)

  • House Lights: Controlled by DMX on Universe 4 addresses 1-6

  • Moat Theatre Logo Gobos: Controlled by DMX

Circuits

  • FOH Bar (Motorised): 12 No. 16a Sockets (1-12)

  • FOH Boom Left: 6 No. 16a Sockets (13-18)

  • FOH Boom Right: 6 No. 16a Sockets (19-24)

  • LX 1 (Motorised): 12 No. 16a Sockets (37-48)

  • LX 2 (Motorised): 12 No. 16a Sockets (49-60)

  • LX 3 (Motorised): 12 No. 16a Sockets (61-72)

  • LX 4: Restricted to LEDs only

  • Down Stage Left: 6 No. 16a Sockets (85-90)

  • Up Stage Right: 6 No. 16a Sockets (91-96)

Visitor Supply: 63amp 3-phase isolator Stage Right for Touring Dimmers

Lighting Inventory

  • 6 x ETC Source 4 Zoom 25/50

  • 3 x ETC Source 4 Zoom 15/30

  • 5 x ETC Source 4 Junior Profiles 25/50 575W

  • 6 x Cameo Thunderwash 600 RGBW Floods

  • 4 x Selecon Aurora 1.2 KW Cyc Floods

  • 5 x Robert Juliat Fresnel 1 KW

  • 11 x Robert Juliat Fresnel 1.2 KW

  • 7 x Tomas Par Can CP62 1000W

  • 10 x Eurolite RGBA Led Par (20 degree beam angle)

  • 4 x Elation Par LED Zoom 60W

  • 6 x Stairville Retro Par RGBW 200W (25 degree beam angle)

  • 4 x Mac Aura XB (not movable)

  • 2 x LED TMH X4 (not movable)

  • 2 x Hero Wash 300 FC (not movable)

  • 2 x Varytek Hero Wash 715 HEX LED

  • 4 x Hero Wash 712 Z RGBW Zoom

Lighting Accessories

  • 2x Soca Fan Out 6x16amp

  • 6x Standard Boom Arms

  • 2x Free-standing 1.5 meter booms with Tank Trap

  • 4x DMX Splitters (Located in each corner of the stage)

Sound Spec

Mixing Desk

  • Sound Craft Expression 3 Digital Mixing Console
    Link

PA System

  • Nexo M6: 8 (Flown over Pros Arch, 4 per side)

  • Nexo PS10: 1 (Flown over Pros Arch Centre)

  • Nexo LS600 Subs: 2 (1 Each Side on the Deck)
    Nexo M6 Datasheet

Stage Box

  • Digital: Sound Craft 16 Channel Stage Box with 8 Aux’s
    Link

Amplifiers

Monitors

Analogue Stage Box

  • Outputs and Sends (D.S.R & D.S.L): 10 Mic/Line outlets, 2 Mic/Line Sends

Microphones

  • 6x SM58 Vocal Mics

  • 3x SM57 Dynamic Mics

  • AKG Drum Mic Set

  • 4x Riffle Mics

  • 2x Prodipe TT1 PRO-Lanen

  • 1x AKG D5

  • 4x JTS UF-20R Handheld Radio Mics

DI Boxes

  • 9x Assorted DI Boxes

Stands

  • Boom Stands: 10

  • Straight Stands: 4

  • Short Stands: 4

Streaming/Show Recording

  • DATA VIDEO PTC 140 Full HD Cameras: 3
    Link

  • Black Magic ATEM MINI PRO
    Link

  • RMC 180 PTZ Camera Control Unit
    Link

Foyer Sound

  • Mixing Amplifier: Located at Box Office with iPod connection; Tannoy for Announcements.

  • Speakers: Wall-mounted in Foyer and Exhibition Space, selectable as 2 zones.

  • Mic Outlet: Available in Foyer and Exhibition Space.

  • Show Relay: Duplicates Pre/Interval/Post Show Music in Auditorium.

Stage Communication

  • Master Station: Stonewood Audio CMS2 LSM-1,2 Ring at Stage Managers Desk.

  • Show Relay: To Green Room and Dressing Rooms 1 and 2.

  • Talkback Headsets: 3 normally located at sound and lighting control room & D.S.R.

Stage Flying

  • Motorised Bars: 4 (Rated to 500kg)

  • 5 Line Hand Winch for LX 4: SWL 250kg

  • Manual Hemp Sets: 7 (Rated at 100kg SWL)

Drapes and Masking

  • House Curtain: 1 No. Velour, hand-drawn from Stage Right.

  • Masking Legs: 8 No. Black Wool Serge, 1,500mm Wide x 5,500mm Drop.

  • Mid Tab: 2 No. Full Black Wool Serge, 6,250mm Wide x 5,500mm Drop.

  • Borders: 4 No. Black Wool Serge, 12,000mm wide x 1,500mm Drop.

  • Cyclorama: 1 No. Filled White Cloth, 12,500mm Wide x 5,500mm Drop; 2 No. Full Black Wool Serge.

Equipment for Access

  • Genie GR15 (Working Height 6,500mm)
    Valid MEWP certificate required.

  • Wooden A-Frames: 10ft and 8ft

Cabling

  • Assortment of:

    • XLR cables

    • 13amp plug boards

    • Power converters

    • 5-pin DMX cables

    • 16amp TRS cables

Note: We recommend bringing your own cables should you be concerned that the house will not stock enough.

Additional Information

For the LX Plan and Circuit Layout, please email technical@moattheatre.com.
